RM-208 8-ch Form C 5 A Power Relay Board for DIN-rail Mounting
RM-208 CR relay board with eight channels, each fitted with two Form C relays rated 5 A @ 250 VAC. Designed for DIN-rail mounting, with a status LED on every channel.
- Eight channels, each with two Form C relays
- Contact rating 5 A @ 250 VAC
- 24 V power relay type
- Reverse polarity protection
- Status LED on every channel
- DIN-rail mounting on TS-15, TS-32 or TS-35 rails
1 714,10 kr per stk.
| 1–9 stk. | 1 714,10 kr | |
|---|---|---|
| 10–30 stk. | 1 662,16 kr | −3 % |
| 31+ stk. | 1 630,99 kr | −5 % |
Produktinformasjon "RM-208 8-ch Form C 5 A Power Relay Board for DIN-rail Mounting"
RM-208 CR is an 8-channel relay board in the RM series. Each channel carries two Form C relays rated 5 A @ 250 VAC, so one channel can switch two independent contact sets from a single 24 V power relay input.
The board mounts on TS-15, TS-32 or TS-35 DIN rails. Reverse polarity protection guards against incorrect wiring, and an LED on each channel shows its status, which helps with commissioning and fault finding in control cabinets.
Choose this variant when you need eight relay channels with dual Form C contacts. The RM series also includes 4-channel and 16-channel versions with different relay configurations.
| Product type: | Relay board |
|---|---|
| Relay outputs: | 8 |
| Operating temperature: | -20 ~ 70°C |
| Mounting: | DIN-rail |
Spesifikasjoner
| Relay Output | |
|---|---|
| Channels | 16 X FORM C |
| Type | 24 V Power Relay |
| Contact Rating | 5 A @ 250 VAC |
| Mechanical | |
| Dimensions (mm) | 169 mm x 87 mm x 63 mm (L x W x H) |
| Installation | DIN-rail mounting |
| Environment | |
| Operating Temperature | -20 ~ 70°C |
| Storage Temperature | -20 ~ 70°C |
| Humidity | 5% ~ 90% RH, non-condensing |
Spesifikasjoner som oppgitt av produsenten. Med forbehold om endringer.
