I-7188EX-MTCP Programmable Modbus TCP to RTU Gateway, RS-232/485
Palm-sized programmable serial-to-Ethernet gateway that links RS-232/RS-485 devices to Ethernet and converts Modbus TCP to Modbus RTU for SCADA and HMI systems.
- Modbus TCP to RTU gateway for SCADA and HMI connectivity
- One 10BASE-T RJ-45 Ethernet port plus RS-232 and RS-485 serial ports, up to 115200 bps
- Programmable in C with the MiniOS7 operating system and development toolkit
- 80188-40 CPU with 512 KB flash, 512 KB SRAM and 2 KB EEPROM
- Real-time clock and built-in watchdog timer
- I/O expansion bus supporting one X-board
2 846,45 kr per stk.
| 1–9 stk. | 2 846,45 kr | |
|---|---|---|
| 10–30 stk. | 2 763,34 kr | −3 % |
| 31+ stk. | 2 711,40 kr | −5 % |
Produktinformasjon "I-7188EX-MTCP Programmable Modbus TCP to RTU Gateway, RS-232/485"
The I-7188EX-MTCP is a palm-sized programmable device server that connects RS-232 and RS-485 serial devices to an Ethernet network. It also acts as a Modbus TCP to RTU gateway, so SCADA and HMI software that speaks Modbus TCP can reach serial field devices without custom drivers.
Engineers can extend the unit with the included C language development toolkit, which provides XServer and Modbus libraries, running on the MiniOS7 operating system. The ordering code I-7188EX-MTCP CR is the blue-cover version of this gateway.
Hardware features include an 80188-40 CPU, 512 KB flash and 512 KB SRAM, a real-time clock, a watchdog timer and a 64-bit hardware serial number. An I/O expansion bus accepts one X-board for added analogue or digital I/O or serial ports.
Applications
- Incorporating serial RS-232/RS-485 devices into Ethernet networks
- Modbus TCP access to serial Modbus RTU devices for SCADA and HMI systems
- Serial device integration with SCADA packages such as Indusoft, ISaGRAF, DASYLab, Trace Mode, Citect and iFix
| Product type: | Gateway |
|---|---|
| Interface: | Ethernet, RS-232, RS-485 |
| Protocol: | Modbus TCP |
| Ports: | 1 x RJ-45, 1 x RS-232, 1 x RS-485 |
| Power input: | +10 ~ 30 VDC |
| Operating temperature: | -25 ~ +75 °C |
| Mounting: | DIN-rail |
| Housing: | Palm-sized |
Spesifikasjoner
| Software | |
|---|---|
| OS | MiniOS7 |
| Development | C Language |
| CPU Module | |
| CPU | 80188, 40 MHz or compatible |
| 64-bit Hardware Serial Number | Yes |
| EEPROM | 2 KB |
| Flash | 512 KB |
| NVRAM | 31 Bytes |
| SRAM | 512 KB |
| Real Time Clock | Provide seconds, minutes, hours, day of week, month, year |
| Watchdog Timer | Yes |
| LED Indicators | |
| Status | 1 x System |
| I/O Expansion | |
| I/O Type | X-board |
| Ethernet | |
| Ports | 1 x RJ-45, 10 Base-T |
| COM Ports | |
| Ports | 1 x RS-232, 1 x RS-485 |
| Baud Rate | 115200 bps Max. |
| Power | |
| Input Range | +10 ~ 30 VDC |
| Consumption | 2.0 W |
| Mechanical | |
| Dimensions (mm) | 72 x 123 x 33 (W x H x D) |
| Installation | DIN-Rail Mounting |
| Environment | |
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -40 ~ +80 °C |
| Humidity | 5 ~ 90 %, Non-condensing |
Spesifikasjoner som oppgitt av produsenten. Med forbehold om endringer.
